YD-22 Hydraulic Diesel Engine Railway Tamper Tool
Product Description
YD-22 Hydraulic Diesel Engine Railway Tamper Tool
YD-22 tamping machine is our upgrading products by collecting end-users’ experience at home and abroad, adopting new material and technology. It’s suitable for tamping operation on various rail and sleeper track after the overhaul and medium maintenance ballast cleaning operation, and also suitable for tamping operation on the new track ballast bed. It adopts single cylinder structure, high-power, water-cooled diesel engine. It has the features that compact structure, big vibration force, good tamping quality, superior performance, safe and reliable, high efficiency, fully meet the needs of the railway ballast tamping operation.
Product
Description
Model
YD-22 Rail Tamping Machine
Dimension
1390*750*1600mm
Material
Metal and Stainless Steel
Color
Yellow or Orange
Application
Rail Track Ballast Tamping Operation
Motive power
SF190 Model Diesel Engine Power :7kW
Hydraulic pressure
5~6MPa
Vibration frequency
66.7Hz
Exciting force
22kN
Max.under thrust force
110mm±10mm(Beneath The Sleeper)
Production efficiency
≥ 270pieces/(Group/Per Hour)
Main frame net weihgt
450KG
We manufactures Rail E Clip and Clamp, High Tensile Bolt with Nut and Washer, Rail Base(Tie) Plate, Rail Fish Plate, Rail Shoulder, Rail Screw and Spike, Fish Bolt with Nut and Washer, Rail Dowel, Rubber and EVA Pad, Crane Rail and Light Rail, Wooden Sleeper, Auto Bolt and Other spare parts.
Kunshan Alex Railway Fastening Co., Ltd manufactures railway fasteners and standard components. As a leading railway fasteners manufacturers in China,with production license of Chinese railway Ministry, advanced technology, high precision inspection instruments and service, our products have been widely exported the USA, Germany, Spain, Japan, Australia, Italy, Netherlands, Belgium, Poland, the UK, India, and South Africa etc.
1. Screw spike/Coach screw/Drive screw/Sleeper Screw, Dog spike/Railroad spike/Lock spike/Cut spike,etc.
2. Rail clip/ Tension clamp/ E, R, SKL clip/ E clip/ Deenik clip
3. Swivel Bolts/ Track Bolt/ Special bolts/ U bolts/ J bolts/ Anchor bolts/ Foundation bolts/ Stud bolts/ Rod bolts/ Curved bolts/ Tunnel bolts
4. Tie plate/ Base plate / Rail plate/ Rail fixing base/ Rail Pads/ Sole plate/ Sole pad
5. Fish plate / Joint bar / Rail joint/ Splice Bar
6. Track bolt/ T bolt / Rail bolt/ Clamp bolt/ Inserted bolt/ Clip bolt/ Fish bolt/ Square bolt/ Rod bolt /Rail joint bolt
7. Clamp plate/ Rail spring clamp/ Anchor plate/ Steel clip
8. Rail Shoulder/ Rail sleeper Inserts/ Rail Anchors for rail sleepers
9. Plastic dowel / Guide plate/ Nylon insert
We are trying to supply the best products at the best price!
light portable rail drilling machine
Packaging Details:
Plywood case (export standard) OR wooden box packing
Delivery Detail:
2 weeks after receive payments,stocks
We can provide products according to customers drawings and samples.Our main products are as following:
