NLB-300 ENGINE rail track bolt wrench ALEX RAILWAY
Product Description
NLB-300 ENGINE rail track bolt wrench ALEX RAILWAY
Selling point
single head petrol engine
with 4 rotary wheels at the base
powerful impact force
Application
NLB-300 type single head petrol engine rail track bolt wrench is suitable for loosening & fastening the tie bolt & nut of railway track. It adopts a traveling unit with 4 rotary wheels at the base. Therefore, it’s suitable for traveling on land as well as on rail with good mobility.
Features
It with features of powerful impact force and integrated operating system, it can supply the demand of the locking torque to fasten the rail fastenings conveniently and quickly.
Technical parameters
Rail bolt wrench main parameter
Type
NLB-300 rail bolt wrench
Main shaft rev
780r/min
Rated loosing torger
≥300 N•m
Rated fastening torque
≥150 N•m
Max. output torque
1100 N•m
Working efficiency
≤10 pieces/min
Engine model
Honda GX160 petrol engine
Engine rated power
4kw
Engine rated rev
3600r/min
Weight
60kg
Dimention
1300*510*760
We manufactures Rail E Clip and Clamp, High Tensile Bolt with Nut and Washer, Rail Base(Tie) Plate, Rail Fish Plate, Rail Shoulder, Rail Screw and Spike, Fish Bolt with Nut and Washer, Rail Dowel, Rubber and EVA Pad, Crane Rail and Light Rail, Wooden Sleeper, Auto Bolt and Other spare parts.
Kunshan Alex Railway Fastening Co., Ltd manufactures railway fasteners and standard components. As a leading railway fasteners manufacturers in China,with production license of Chinese railway Ministry, advanced technology, high precision inspection instruments and service, our products have been widely exported the USA, Germany, Spain, Japan, Australia, Italy, Netherlands, Belgium, Poland, the UK, India, and South Africa etc.
1. Screw spike/Coach screw/Drive screw/Sleeper Screw, Dog spike/Railroad spike/Lock spike/Cut spike,etc.
2. Rail clip/ Tension clamp/ E, R, SKL clip/ E clip/ Deenik clip
3. Swivel Bolts/ Track Bolt/ Special bolts/ U bolts/ J bolts/ Anchor bolts/ Foundation bolts/ Stud bolts/ Rod bolts/ Curved bolts/ Tunnel bolts
4. Tie plate/ Base plate / Rail plate/ Rail fixing base/ Rail Pads/ Sole plate/ Sole pad
5. Fish plate / Joint bar / Rail joint/ Splice Bar
6. Track bolt/ T bolt / Rail bolt/ Clamp bolt/ Inserted bolt/ Clip bolt/ Fish bolt/ Square bolt/ Rod bolt /Rail joint bolt
7. Clamp plate/ Rail spring clamp/ Anchor plate/ Steel clip
8. Rail Shoulder/ Rail sleeper Inserts/ Rail Anchors for rail sleepers
9. Plastic dowel / Guide plate/ Nylon insert
We are trying to supply the best products at the best price!
NLB-300 ENGINE rail track bolt wrench ALEX RAILWAY
Packaging Details:
Plywood case (export standard) OR wooden box packing
Delivery Detail:
2 weeks after receive payments,stocks
