Product Description

Steel Rail welder for railway construction

Packaging Details:	Plywood case (export standard) OR wooden box packing
Delivery Detail:	2 weeks after receive payments,stocks

Rail movable air pressure welding equipment is mainly used in rail welding, this equipment is pressure type way of pushing convex, pressing machine for the rail bottom position, ensure the rail head in laymen, on the pressure welding machine is equipped with upsetting control valve, may reduce the delay operation. Compared with similar products, the equipment have the characteristics of unique design, reasonable design, simple operation, etc.

Part 1. pressing machine part

1.1, pressing machine maximum working stroke: 100mm

1.2, press the rated working pressure: 35Mpa

1.3, press the maximum working pressure: 40Mpa

1.4, push convex machine maximum working stroke: 120mm

1.5, push convex cylinder maximum working pressure: 45MPa

1.6, push the convex press cylinder maximum pushing convex capacity: 452kN

1.7, pressing machine quality: 230 kg

1.8, pressing machine dimensions: 1320 mm* 635 mm* 330mm

Part 2 .hydraulic pump station

2.1 motor voltage: 380V

2.2 motor speed: 1440r/min

2.3 pump station flow: greater than or equal to 4L/min

2.4 fuel tank capacity: 20L

Part 3 .water pump:

3.1 pump type: YSB (AOB) -25

3.2 pump voltage: 380V

3.3 flow: 25L/min

Packaging & Shipping

Packaging Details: Plywood case (export standard) OR wooden box packing

Delivery Detail: 2 weeks after receive payments,stocks
